Square Ceramic Tiles
Product introduction:
Square ceramic is the most popular products of our company. Square ceramic can be used widely in hoppers,chutes,ball mills,feeders in cement,coal,mine,chemical industry etc. Square ceramic from BOMAI includes ceramic plate and ceramic mosaic. Specific size can be customized according to customers' requirements.
Advantage:
corrosion reisistance
impact resistance
no pollution
strong wearability
Chemical Composition and Physical Properties:
| Series | BM92 | BMG95 |
| AL2O3(%) | 92±0.5 | 95±0.5 |
| Bending strength(Mpa) | ≥220 | ≥250 |
| Compressive strength(Mpa) | ≥1050 | ≥1300 |
Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
| Rockwell hardness(HRA) | ≥82 | ≥85 |
Wear volume(cm3) | ≤0.25 | ≤0.2 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 |
Specification Available:
| Type | Length(mm) | Width(mm) | Height(mm) |
| Flat ceramic liner | 50~150 | 25~100 | 6~50 |
| Welding ceramic liner | 50~150 | 30~100 | 10~50 |
| Trapezoidal ceramic liner | 50~150 | 20~100 | 8~50 |
| Ceramic Mosaic | |
| Length*Width(mm) | Height(mm) |
| 10*10 | 3~10 |
| 17.5*17.5 | 3~10 |
| 20*20 | 4~10 |
| 25*25 | 4~10 |
