Customized Alumina Tile
video

Customized Alumina Tile

high hardness, impact resistance,trapezoidal tile
Send Inquiry
Product Introduction

Product introduction

TITAN Customized Alumina Tiles provide tailored wear protection for industrial equipment exposed to continuous abrasion. Available in different shapes, dimensions, thicknesses, and alumina grades, they can be designed around specific equipment layouts to simplify installation and improve lining coverage.

Wear-resistant alumina tiles is an excellent wear-resistant product. It is generally pasted on the inner wall of chute and pipeline, and is widely used in the industrial field. Titan produces alumina tiles of various specifications and different alumina content. We also can be customized according to the requirements to meet the needs of different customers.

Product Overview

product-900-900

Customized Alumina Tiles are engineered ceramic components made primarily from aluminum oxide (Al₂O₃). They are designed to protect equipment surfaces against abrasive materials, helping reduce wear on metal structures and other vulnerable areas.

Unlike standard ceramic tiles with fixed dimensions, custom-made alumina tiles can be produced according to equipment drawings, installation requirements, and working conditions. This makes them suitable for projects involving irregular surfaces, limited installation space, special fixing methods, or non-standard lining arrangements.

TITAN provides customized ceramic tile solutions for industrial wear protection, with different material grades and configurations available according to project requirements.

Application

Alumina tiles are widely used in material conveying equipments such as hoppers, chutes, pipelines of steel, cement, coal, mine chemical industry etc.




Properties


high

hardness

impact

resistance

corrosion resistance

super abrasion resistance



Chemical composition and physical properties



Series BM92 BMG95 BME95 BMZTA BMZR
AL2O3(%) 92±0.5 95±0.5 95±0.5 ≥75 -
ZrO2(%) - - - ≥21 94.8±0.5
Bending strength(Mpa) ≥220 ≥250 ≥300 ≥400 ≥800
Compressive strength      (Mpa) ≥1050 ≥1300 ≥1600 ≥2000 -

Fracture toughness

(MPam1/2)

≥3.70 ≥3.80 ≥4.0 ≥4.5 ≥7
Rockwell hardness(HRA) ≥82 ≥85 ≥88 ≥90 ≥88
Wear volume(cm3) ≤0.25 ≤0.2 ≤0.15 ≤0.05 ≤0.02
Bulk density(g/cm3) ≥3.6 ≥3.65 ≥3.7 ≥4.1 ≥5.9



Specification Available



Size Length Width Height
Alumina tiles(without hole) 50-150 25-100 6-50
Alumina tiles(holes) 50-150 30-100 10-50
Trapezoidal alumina tiles 50-150 20-100 8-50






product-900-506

product-900-506

FAQ





01.Can TITAN manufacture alumina tiles according to customer drawings?

Yes. Customized dimensions and special profiles can be discussed based on technical drawings, samples, or clearly defined measurements.

02.What alumina contents are available?

Common options include 92% and 95% alumina. The appropriate grade depends on the required wear resistance, impact conditions, and project requirements.

03.Can you produce special-shaped ceramic tiles?

Yes. Special profiles, chamfered edges, holes, grooves, and other features can be evaluated according to the drawing and manufacturing feasibility.

04.What thickness can customized tiles have?

Thickness depends on the equipment space, wear allowance, installation method, and mechanical requirements. Please provide your drawing or required dimensions for confirmation.

05.How are customized ceramic tiles installed?

Installation may involve ceramic adhesive, mechanical fixing, or a composite lining arrangement. The appropriate method depends on the equipment structure and operating conditions.

06.What information is required to obtain a quotation?

Please provide the tile dimensions or drawing, material grade, installation requirements, application details, and order quantity. TITAN can then review the specifications and prepare a quotation.

Need alumina ceramic tiles made to your specifications?

Send TITAN your drawings, dimensions, required alumina grade, and estimated quantity. Our team will review your requirements and help confirm a suitable customized ceramic tile solution for your equipment.
