92% Alumina Tiles 150*100*25mm





92% alumina tiles 150*100*25mm are ceramic materials composed of aluminum oxide (Al2O3). Among ceramic tiles, alumina ceramic tiles with excellent wear resistance are very popular.Alumina ceramic tiles are made of high-purity alumina and have good mechanical and thermal properties.







92% alumina tiles 150*100*25mm have high hardness and wear resistance, making them ideal for protecting surfaces from wear and impact. Its Mohs hardness is 9, ranking second after diamond. In addition, it can withstand high temperatures and has excellent thermal shock resistance.





92% alumina tiles 150*100*25mm are widely used in high-wear applications such as conveying systems, chutes, hoppers, cyclones, and pipelines. These provide excellent solutions for linings or protection of equipment against wear and corrosion.





Alumina liners can be installed in various ways, such as direct bonding, mechanical fixing, welding, etc. The exact installation process varies depending on the use and the condition of the surface.









Series	BM92
AL2O3(%)	92±0.5
ZrO2(%)	-
Bending strength (Mpa)	≥220
Compressive strength (Mpa)	≥1050
Fracture toughness (MPam1/2)	≥3.70
Rockwell hardness (HRA)	≥82
Wear volume(cm3)	≤0.25
Bulk density(g/cm3)	≥3.6



Size	Length	Width	Height
Alumina Ceramic Tile(Without Hole)	50-150	25-100	6-50
Alumina Ceramic Tile(Hole)	50-150	30-100	10-50
Alumina Ceramic Tile(Trapezoidal)	50-150	20-100	8-50
