Alumina Ceramic Curved Arc Lining Tiles
Product Material:Alumina Ceramic
AL2O3 Content(%):92/95
Product Color:White
Hardness(Mohs):9
Bulk density(g/cm3) ：≥3.6/≥3.7
Customized: available
Product Description
Alumina Ceramic Curved Arc Lining Tiles are a material used to protect against corrosion and abrasion, and are commonly used for internal liners in equipment such as pipelines, storage tanks and reactors. It is made of high hardness, high wear resistance ceramic material, and its special arc design can improve the fluidity and temperature distribution of the fluid, thereby improving the efficiency and stability of the equipment.
Advantages
1. Strong wear resistance: Alumina Ceramic Curved Arc Lining Tiles has extremely high hardness and wear resistance, which can be served for a long time without wear.
2. Strong corrosion resistance: the curved ceramic liner has stable chemical properties and strong acid and alkali corrosion resistance, and can be used in various corrosive environments.
3. Strong impact resistance: the curved ceramic liner has extremely high impact resistance and is not easy to be damaged by external forces.
4. Environmental protection and energy saving: the curved ceramic lining plate is natural and harmless, will not pollute the environment, and has good environmental performance. At the same time, its smooth surface can effectively reduce fluid friction resistance and save energy.
Application
Alumina Ceramic Curved Arc Lining Tiles are widely used in cyclones, mainly used to separate and filter particles, with good wear and corrosion resistance.
As a common separation equipment, the main principle of cyclone is to use centrifugal force to separate particles in the medium. However, particles in the medium are prone to wear and corrosion of equipment, especially under some harsh working conditions.
In order to solve this problem, curved ceramic liners came into being. It not only protects the equipment from particulate wear and corrosion, but also improves the separation efficiency.
Curved ceramic liners have very superior properties, and their wear and corrosion properties are much better than other materials. In addition, it is relatively easy to clean and maintain, especially when it is necessary to handle highly rigid and corrosive particles in production.
Specification
| Series | BM92 | BMG95 | BME95 |
| AL2O3(%) | 92±0.5 | 95±0.5 | 95±0.5 |
| ZrO2(%) | - | - | - |
| Bending strength(Mpa) | ≥220 | ≥250 | ≥300 |
| Compressive strength (Mpa) | ≥1050 | ≥1300 | ≥1600 |
| Fracture toughness(MPam1/2) | ≥3.70 | ≥3.80 | ≥4.0 |
| Rockwell hardness(HRA) | ≥82 | ≥85 | ≥88 |
| Wear volume(cm3) | ≤0.25 | ≤0.2 | ≤0.15 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 | ≥3.7 |
