Yttria Stabilized Zirconia Beads
video

Yttria Stabilized Zirconia Beads

Product Name:Yttrium Stabilized Zirconia Beads
Properties:PPM abrasion grade,Large specific gravity,High toughness,no crackle
Applied to the ultra-fine grinding and dispersion of materials.
Send Inquiry
Product Introduction

Introduction:

High-performance zirconium products called yttria stabilized zirconia beads are created by a unique technique combining yttrium and zirconium dioxide. Because of their numerous great qualities, yttrium stabilized zirconium beads can be utilized extensively in a variety of industrial production processes, particularly in areas with significant wear and corrosion.



Feature of Yttrium Stabilized Zirconia Beads :

1.Elevated density: Yttria stabilized zirconia beads have an extremely high density of more than or equal to 6.0g/cm³, which is comparable to half of steel.
2. Low expansion: Yttrium-stabilized zirconia beads have a very low thermal expansion coefficient and are suited for high-temperature applications because they do not distort at higher temperatures.
3. High hardness: It is widely employed in precision grinding and other industries because of its Mohs hardness, which may reach level 9, which is significantly higher than that of most metals and conventional alumina abrasives.



Application:

Yttria stabilized zirconia beads applied to the ultra-fine grinding and dispersion of"zero pollution" and high viscosity and high hardness materials, such as:non-metallic minerals,pesticides,electronic ceramics, magnetic materials,titanium dioxide,medical supplies,pigments,dyes,inks,special chemical industries wait.



Specification

Series

BMYG95

ZrO2 (%)

95±0.5

Y2O3 (%)

5

Hardness (Mohs)

9

Real density (g/cm3)

≥6.0

Bulk density (g/cm3)

3.65

Self wearing rate (%)

2ppm

Dimension (mm)

0.1    0.2     0.3

0.4-0.6    0.6-0.8      0.8-1.0

1.0-1.2    1.2-1.4      1.4-1.6

1.8-2.0    2.0-2.2       2.2-2.4

2.4-2.6    2.6-2.8       2.8-3.0

3.0-3.2    3.2-3.4       3.6-3.8

4     5     8    10    15

20    25     30     40     50



Product Photo


01



Production process

05

APPLICATON

product-900-506
