Square Alumina Wear Resistant Mosaic Lining Sheet
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet
Al2O3 ： 92% 95%
Bending strength(MPa) ： >=220 250 300 400 800
Compressive strength(MPa) ： >=1050 1300 1600 2000
Fracture toughness (MPam1/2) ： >=3.7 3.8 4.0 4.5 7
Rockwell hardness (HRA)： >=82 85 88 90
Loss bulk(cm3)： <=0.25 0.2 0.15 0.05 0.02
Bulk density(g/cm3) ： >=3.6 3.65 3.7 4.1 5.9
Feature:easy installation, impact resistance, corrosion resistance.
Product Introduction
There are many ways to call wear-resistant alumina ceramic linings, such as: alumina ceramic linings, high alumina linings, wear-resistant ceramic linings, alumina ceramic patches, alumina linings, etc.
Feature
1.High hardness, its Rockwell hardness can reach hra80-90;
2.Its wear-resistant performance is excellent, and its wear-resistant performance can be higher than that of manganese steel and high chromium cast iron, which can prolong the lifetime of the equipment by more than ten times;
3.Moreover, the weight of the products is very light, and its density is 3.65g/cm3, which can greatly reduce the load of the equipment.
4.The chip has strong adhesion and good heat resistance on the equipment, and it can run for a long time without aging at 350 ℃
5.High-temperature wear or high-temperature erosion. The data shows that the service life of wear-resistant ceramics is ten to twenty times higher than that of cast stone, wear-resistant alloy cast steel, steel plastic, steel rubber and other materials.
Chemical Composition and Physical Properties
| Series | BM92 | BMG95 |
| AL2O3(%) | 92±0.5 | 95±0.5 |
| Bending strength(Mpa) | ≥220 | ≥250 |
| Compressive strength(Mpa) | ≥1050 | ≥1300 |
| Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
| Rockwell hardness(HRA) | ≥82 | ≥85 |
| Wear volume(cm3) | ≤0.25 | ≤0.2 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 |
Specification Available
| Length*Width(mm) | Height(mm) | NOTE |
| 10*10 | 3-10 | paste |
| 17.5*17.5 | 3-10 | paste |
| 20*20 | 4-10 | paste |
| 25*25 | 4-10 | paste |
Application
Square Alumina Wear Resistant Mosaic Ceramic Lining Sheet is widely used in power plants and metallurgical plants, mainly as wear-resistant materials for the inner walls of various industrial equipment.
Our product
The production process
FAQ
1.Q: What is the size in your products?
A: Our common size is 0.1mm-50mm. We can also produce according to your request.
2.Q: What is your terms of delivery?
A: FOB, CFR, CIF.
3.Q: Can you accept small quantity sample order before production?
A: Yes, we can offer sample for your testing first before production, but the customers have to pay the courier cost.
4.Q: What is your production time?
A: Generally, it will take 5 to 7 days after receiving your advance payment.
The specific delivery time depends on the items and the quantity of your order.
5.Q: What is your terms of payment?
A: T/T 50% as deposit, 50% balance against the copy of original B/L.
We'll show you the photos of the products and the copy of original B/L before you pay the balance.
