Abrasive Resistant Ceramic Plywood
Elongation At Break: ≥250%
Working Temperature: -50-200℃
Certifified: ISO 9001
Details
The reason why the ceramic rubber plate has such a powerful function is that there are hundreds of independent small ceramic blocks vulcanized on each ceramic rubber plate. Traction, effectively prevent the conveyor belt from slipping. The high-quality rubber of the bottom layer has a good impact resistance effect, which maximizes the service life of the roller.
Features
Ceramic plywood has strong wear resistance and high friction, has a unique self-cleaning ability, and can also perform quite well in harsh working environments such as humidity.
Application
1. The conveyor belt's speed is within 4.5m/s.
2. The conveyed material's temperature is within 80℃.
3. It is suitable for high-abrasion and slippery materials.
Technical Data
| Bulk Density(G/Cm³) | 1.4 |
| Tensile Strength At Break(MPa) | ≥14 |
| Elongation At Break(%) | ≥250 |
| Shore Hardness(HA) | 48~65 |
| Adhesive Between Steel &Rubber( MPa) | ≥3.5 |
| Adhesive Between Rubber&Ceramic(MPa) | ≥3.5 |
| Thermal Conductivity(Normal Temperature)(W/M·K) | 2 |
| Aging Period ( Years) | ≥1.5 |
| Working Temperature(℃) | -50-200 |
