Product Introduction:
The ceramic tile liner is the regular stock products of the company. Alumina tile liners has charaters of wear resistance, high temperature resistance, corrosion resistance, esay installation and light weight, which can effectively product the machines against wear damage. Wear resistant ceramic tile liner are widely used in hoppers, rubber belts, pipes,elbows, valves, fan blades, chutes, ball mills, feeders, bunkers and other processing equipment of the steel, thermal power, cement, coal, mine, port chemical industry and so on.
As an industry wear resistant ceramic manufacturer, Titan ceramic tile liner including 92% AL2O3 series, 95% AL2O3 series. And different shapes including flat tile, welding tile and Trapezoidal tile.Since its establishment, the company has been taking the quality management as the key point and has won a good reputation in the market.
Features:
The ceramic tile liner is mainly made of calcined α-alumina powder. After being pressed and formed, it is sintered at a high temperature of a tunnel kiln above 1600 degrees. The hardness can reach HRA85 or more. It has strong wear resistance in corrosive environment. It can be fixed in the equipment by pasting, welding, bolting, etc., with low density, light weight, and easy installation and replacement.
Product Application:
Widely used in thermal power, steel, smelting, machinery, coal, mining, chemical, cement, port and coal conveying, material conveying system, pulverizing system, ash discharge, dust removal system and other mechanical equipment with large wear and tear.
Chemical Composition and Physical Properties:
| Item/Product | 92 series | 95 series |
| AL2O3 (%) | ≥92 | ≥95 |
| Hardness(Mohs) | 9 | 9 |
| Water Absorption (%) | ≤0.02 | ≤0.02 |
| Fracture toughness(Mpa) | 3.65 | 3.75 |
| Bending strength(Mpa) | 255 | 275 |
Specification Available:
| Size | Length | Width | High |
| Flat tile liner | 50~200 | 25~150 | 6~50 |
| Welding tile liner | 50~150 | 30~150 | 8~30 |
| Trapezoidal tile liner | 50~150 | 20~150 | 8~30 |
Picture:
