Wear Liner Plates
Product introduction:
The wear liner plate is made by dry pressing and high-temperature calcining production and processing with aluminum oxide powder as the main raw material. It has extremely high hardness, corrosion resistance and good chemical stability, and can withstand the impact and wear of high concentration and large particles for a long time. Its hardness is second only to diamond.
The wear linerplate is often used on the inner wall of pipelines and the inside of equipment, which can slow down the wear and tear caused by the grinding of raw materials on equipment and the impact of materials on pipelines during transportation.
Chemical composition and physical properties:
| Item | 92 Series | 95 Series |
| AL2O3(%) | ≥92 | ≥95 |
| Hardness(Mohs) | 9 | 9 |
| Water absorption(%) | ≤0.02 | ≤0.02 |
| Fracture toughness(Mpa) | 3.65 | 3.75 |
| Bending strength(Mpa) | 255 | 275 |
Specification Available:
| Specifications | Length | Width | High |
| Flat plate | 50-200 | 25-150 | 6-50 |
| Weldable plate | 50-150 | 30-150 | 8-30 |
| Trapezoidal plate | 50-150 | 20-150 | 8-30 |
