Product introduction:
Ceramic wear liners are also called wear resistant ceramic lining board, aluminum liner, wear alumina lining board, alumina ceramic board,etc. Ceramic wear liner is a kind of excellent wear-resistant material, which is widely used in all kinds of easily worn industrial equipments. Paste the wear resistant ceramics to the contacting surface can effectively reduce the wear of the equipment and prolong its the service life.
Properties:
excellent wear resistance
impact resistance
easy to install
corrosion resistance
Application:
Ceramic wear liners are widely used in hoppers,pipes,fan blades,chutes,ball mills,bunkers etc in cement, coal, mine, chemical industry etc.
Specification Available:
| Size | Length | Width | Height |
| Flate wear liner | 50-150 | 25-100 | 6-50 |
| Weldable wear liner | 50-150 | 30-100 | 10-50 |
| Trapezoidal wear liner | 50-150 | 20-100 | 8-50 |
Chemical composition and physical properties:
| Series | BM92 | BMG95 | BME95 | BMZTA | BMZ |
| AL2O3(%) | 92±0.5 | 95±0.5 | 95±0.5 | ≥75 | - |
| ZrO2(%) | - | - | - | ≥21 | 94.8±0.5 |
| Bending strength (Mpa) | ≥220 | ≥250 | ≥300 | ≥400 | ≥800 |
| Compressive strength (Mpa) | ≥1050 | ≥1300 | ≥1600 | ≥2000 | - |
| Fracture toughness (MPam1/2) | ≥3.7 | ≥3.8 | ≥4.0 | ≥4.5 | ≥7 |
Rockwell hardness (HRA) | ≥82 | ≥85 | ≥88 | ≥90 | ≥88 |
| Wear volume(cm3) | ≤0.25 | ≤0.2 | ≤0.15 | ≤0.05 | ≤0.02 |
Bulk density (g/cm3) | ≥3.6 | ≥3.65 | ≥3.7 | ≥4.1 | ≥5.9 |
