High Performance Ceramic Tube
Material :Alumina & stain steel
Bending strength(MPa) ：>=220 250
Compressive strength(MPa)： >=1050 1300
Rockwell hardness (HRA) ： >=82 85
Certifified: ISO 9001
Description
High performance ceramic tube is a ceramic material with α-Al2O3 as the main crystal phase. It is formed by static pressure and other processes. It has high purity, good density, good wear resistance, corrosion resistance, high temperature resistance and other excellent properties. Under the same conditions, it is 20 times more wear-resistant than ordinary pipes. The inner and outer walls are smooth, materials can pass freely, the ceramic does not peel off, and the weight is light. It is about 50% lighter than ordinary wear-resistant alloy pipes with the same inner diameter, which reduces weight and saves material costs. The ceramic is dislocated and pasted, and the installation is convenient by welding flanges and other methods, which is easy to carry. It also known as wear-resistant ceramic pipes, ceramic coated pipe.
Technical Specific
|
Series |
BM92H |
BMG95H |
BME95H |
|
AL2O3 (%) |
92±0.5 |
95±0.5 |
95±0.5 |
|
Bulk density(g/cm3) |
≥3.6 |
≥3.65 |
≥3.7 |
|
Compressive strength (MPa) |
≥1050 |
≥1300 |
≥1600 |
|
Bending strength (MPa) |
≥220 |
≥250 |
≥300 |
|
Fracture toughness (MPam1/2) |
≥3.70 |
≥3.80 |
≥4.0 |
|
Rockwell hardness (HRA) |
≥82 |
≥85 |
≥88 |
|
Mohs hardness |
9 |
9 |
9 |
Features of High performance ceramic tube
1. Good wear resistance: The inner lining is wear-resistant ceramic, Rockwell hardness HRA>85, Mohs hardness 9, and good wear resistance.
2. Corrosion resistance: Because ceramics have excellent anti-corrosion properties, they can be used in acid, alkali, and seawater environments.
3. Good high temperature resistance: Ceramics themselves have high temperature resistance, and the high temperature resistance of the pipeline is increased after multi-layer processing, and it has good thermal stability.
4. Low running resistance: The inner wall of the ceramic composite pipeline is smooth, and the smoothness is better than any metal pipeline.
5 Long service life and high cost performance of the product: wear-resistant ceramic pipelines are light in weight and reasonably priced
6. Convenient installation and construction: The weight is lighter than ordinary pipelines, the welding performance is good, and welding flanges and other methods can be used, which is convenient for construction.
Classification
According to the industry, it can be divided into: wear-resistant pipes are usually used in the steel industry, cement industry, mining industry, chemical industry, thermal power industry, port terminal, coal industry and other material conveying systems where the pipes are severely worn.
According to the conveying material, it can be divided into: wind conveying pipes and slurry conveying pipes, pulverizing wear-resistant pipes and coal powder wear-resistant pipes, and wear-resistant pipes for conveying concrete.
According to the conveying temperature, it can be divided into: high-temperature conveying wear-resistant pipes and normal-temperature wear-resistant conveying pipes.
According to the purpose, it can be divided into: powder conveying pipes, gas conveying pipes, and oil conveying pipes.
