Product introduction:
Ceramic wear-resistant bricks are a product with high wear resistance and corrosion resistance. They have the excellent properties of alumina ceramics, can effectively reduce the impact of abrasive materials on equipment, and play a good protective role. They are the choice of many industrial enterprises.
Advantage:
Super wear-resistance
High temperature resistance
Good impact resistance
Specification Available:
| Series | BM92 | BMG95 | BME95 | BMZTA | BMZR |
| AL2O3(%) | 92±0.5 | 95±0.5 | 95±0.5 | ≥75 | - |
| ZrO2(%) | - | - | - | ≥21 | 94.8±0.5 |
Bending strength (Mpa) | ≥220 | ≥250 | ≥300 | ≥400 | ≥800 |
| Compressive strength (Mpa) | ≥1050 | ≥1300 | ≥1600 | ≥2000 | - |
Fracture toughness (MPam1/2) | ≥3.7 | ≥3.8 | ≥4.0 | ≥4.5 | ≥7 |
| Rockwell hardness(HRA) | ≥82 | ≥85 | ≥88 | ≥90 | ≥88 |
| Wear Volume(cm3) | ≤0.25 | ≤0.2 | ≤0.15 | ≤0.05 | ≤0.02 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 | ≥3.7 | ≥4.1 | ≥5.9 |
Specification Available:
| Type | Length(mm) | Width(mm) | Height(mm) |
| Flat tile | 50~150 | 25~100 | 6~50 |
| Weldable tile | 50~150 | 30~100 | 10~50 |
| Trapezoidal tile | 50~150 | 20~100 | 8~50 |
Picture:
