Industrial Ceramic Alumina Tiles
Al2O3 ： 92% 95%
Bending strength(MPa) ： >=220 250 300 400 800
Compressive strength(MPa) ： >=1050 1300 1600 2000
Fracture toughness (MPam1/2) ： >=3.7 3.8 4.0 4.5 7
Rockwell hardness (HRA)： >=82 85 88 90
Loss bulk(cm3)： <=0.25 0.2 0.15 0.05 0.02
Bulk density(g/cm3) ： >=3.6 3.65 3.7 4.1 5.9
Feature:high temperature resistance,impact resistance,corrosion resistance
Product Introduction
Industrial ceramic alumina tiles are also called alumina liners, ceramic tiles, alumina plates. Industrial ceramic alumina tiles refer to the wear resistant products used in industrial equipments to protect it from abrasion. Industrial ceramic alumina tiles have different types including flat tiles, welding tiles and trapezoidal tiles. Besides, we can produces 92% and 95% content ceramic alumina tiles.
Advantages
1High hardness: The Rockwell hardness of Industrial Ceramic Alumina Tiles is above HRA90, the hardness is second only to diamond, far exceeding the wear-resistant performance of wear-resistant steel and stainless steel.
2Excellent wear resistance: its wear resistance is 30 times that of manganese steel and 20 times that of high-chromium cast iron. According to the customer follow-up survey for more than 20 years, under the same working conditions, the service life of the equipment can be extended by at least ten times.
3 Light weight: its density is about 3.6g/cm³, which is only half of that of steel, which can greatly reduce the load of equipment.
4 Strong bonding and good heat resistance: The wear-resistant ceramic sheet can be fixed on the inner wall of the equipment by various methods such as gluing, welding, and rubber vulcanization according to different equipment and working conditions.
5 Corrosion resistance: good resistance to sulfuric acid, hydrochloric acid, nitric acid, strong alkali, salt and other corrosion.
Application
The alumina mosaic tiles are widely used in material conveying equipment, hoppers, pipes, elbows, valves, fan blades, chutes, ball mills, feeders, powder selection equipment, ball milling equipment, etc. Anti-wear conditions.
Specification Available
| Type | Length(mm) | Width(mm) | Height(mm) |
| Flat tile | 50~150 | 25~100 | 6~50 |
| Welding tile | 50~150 | 30~100 | 10~50 |
| Trapezoidal tile | 50~150 | 20~100 | 8~50 |
NOTE: The size can be customized according to customers.
Chemical Composition and Physical Properties
| Series | BM92 | BMG95 | BME95 | BMZTA | BMZR |
| AL2O3(%) | 92±0.5 | 95±0.5 | 95±0.5 | ≥75 | - |
| ZrO2(%) | - | - | - | ≥21 | 94.8±0.5 |
| Bending strength(Mpa) | ≥220 | ≥250 | ≥300 | ≥400 | ≥800 |
| Compressive strength(Mpa) | ≥1050 | ≥1300 | ≥1600 | ≥2000 | - |
| Fracture toughness(MPam1/2) | ≥3.70 | ≥3.80 | ≥4.0 | ≥4.5 | ≥7 |
| Rockwell hardness(HRA) | ≥82 | ≥85 | ≥88 | ≥90 | ≥88 |
| Wear volume(cm3) | ≤0.25 | ≤0.2 | ≤0.15 | ≤0.05 | ≤0.02 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 | ≥3.7 | ≥4.1 | ≥5.9 |
Our product
The production process
FAQ
A: We are the manufacturer in Zibo city, our products have competitive price and quality guarantee. Welcome to send your inquiry!
Q: How about the Delivery time?
A: 5-7days after receiving the deposit based on the MOQ. Normally, 15-20days to finish the order for a 20ft container.
Q: How can you guarantee the product quality?
A: We have the quality control system ISO9001, and it's been followed strictly. We also have the professional QC team, and each our package worker will be in charge of the final inspection according to the QC instruction before packing.
Q: I'd like to know your Payment terms.
A: Basically, the payment terms are T/T, L/C at sight.
Q: Beat Prices?
A:We are the manufacture and our president build this company from nothing. So we are the professionaland will do the best price.
Q:How can I know how my order is being done?
A:We will inspect and test all items in order to avoid damage and missing parts before shipping. The detailedinspection pictures of the order will be sent to you for your confirmation before delivery.
