Ball Mill Lined Brick
Al2O3 ： 92% 95%
Mohs Hardness ： 9
Bulk density(g/cm3) ： >=3.6 3.65
water absorption (%) ： 0.01
Advantage:1. The main component of high-alumina lining brick is high-quality alumina with high purity, which can greatly reduce the pollution caused by grinding materials.
2. Good wear resistance, effectively prolonging the service life of machinery and equipment.
3. The slurry produced by grinding with high alumina balls is fine.
4. It has the characteristics of corrosion resistance, high density and high mechanical strength.
Application:Used for wear-resistant lining of ball mill, widely used in ceramics, cement, paint, pigment, chemical industry, medicine, coating, inorganic mineral powder and other industries.
Details
Ball mill lined brick are also called alumina lining bricks, wear-resistant lining bricks, alumina grinding lining bricks, ball mill lining bricks, high alumina lining bricks, etc. Its main component is alumina powder, which is made after basic mixing, discharging, and trapping, and then sent to a press for molding, and fired at 1650°C.
Advantage
1. Ball mill lined brick has extremely high hardness and wear resistance, and can withstand wear and impact under extreme environments such as high temperature, high pressure, and high load.
2. Alumina wear-resistant lining brick has good corrosion resistance, and can still maintain stable physical properties in acid, alkali, salt and other corrosive environments.
3. Alumina wear-resistant lining brick has excellent insulation performance and thermal conductivity, which can effectively prevent electricity and heat conduction and leakage.
4. Effectively improve grinding efficiency, reduce grinding cost, and reduce product pollution.
Why choose Titan
Here Are Four Reasons Why You Choose Us
Selecting a liner is not simply a matter of choosing the hardest material. The grinding environment, feed size, material hardness, moisture, mill speed and grinding media all influence liner performance.
For example, coarse feed with high impact energy requires a lining system capable of handling repeated mechanical loading. Fine grinding applications may place greater emphasis on abrasion resistance and dimensional stability. If product purity is a major concern, an alumina ceramic mill liner can provide a cleaner contact surface than conventional metallic protection.
Technical specific
| Series | BMNC92 |
| AL2O3(%) | 92±0.5 |
| Hardness(Mohs) | 9 |
| Bulk density(g/cm³) | ≥3.6 |
| Water absorption(%) | 0.01 |
| Color | white |
Application
Abrasion resistant alumina lining bricks is the wear-resistant lining of the ball mill, which is used in ceramics, cement, paint, pigment, chemical industry, medicine, paint, inorganic mineral powder and other industries.
In addition,Ball mill lined brick is the grinding body of fine crushing equipment such as ball mill, vibration mill, pot mill, etc. Its crushing efficiency and wear resistance are better than mullite and natural stone, and it is used in architectural ceramics, Industrial ceramics, electronic ceramics, daily-use ceramics, enamel enterprises, metallurgical enterprises, chemical enterprises, pharmaceutical enterprises, printing ink enterprises and other production enterprises.
Brushing Matters
1. After the ball mill has been aired for 3 days, fill the ball mill with water to reach 50% of the volume of the ball mill, add an appropriate amount of production waste, and then add ball stones exceeding 50% of the ball mill volume, start the ball mill to grind for 2 hours, and release the slurry. Add water to reach 70% of the volume of the ball mill, stop the machine after grinding for 2 hours, drain the water that adheres to the waste, and then put it into normal production.
2. It is strictly forbidden to add only a small amount of ball stones and water when brushing and let the mill run for a long time, which will seriously damage the mill, lining bricks and ball stones.
3. Other precautions
The ball mill should be installed on the site of use as much as possible, and try to avoid installing it at the ball mill manufacturer, so as to prevent the collision of the ball mill during the hoisting process and transportation process, which will cause the lining bricks at the collision site to fall off.
FAQ
01.Are you manufacturer?
02.Do you have stock?
03.Why we could choose you?
Strict quality control-comes form oursophisticated management system.
Professional and warm sales team-since we believe wecan only win via our hard work in a competitive world.
Quick response and excellent presale and after sale service-since we believe our custom-ers deserve all the best service.
04.Can I get best price from you?
05.How should I pay?
06.What certificates and documents do you offer?
