Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Wear-resistant Ceramic Composite Plate For Conveyor Chute
Product Material:Alumina Ceramic + Rubber
Al2O3 ： 92% 95%
Bending strength(MPa) ：>=220 250
Compressive strength(MPa)： >=1050 1300
Fracture toughness (MPam1/2) ： >=3.7 3.8
Rockwell hardness (HRA) ： >=82 85
Loss bulk(cm3)： <=0.25 0.2
Bulk density(g/cm3) ： >=3.6 3.65
Product Size:as customer requirement
Certificate:ISO9001
Customized: available
Product Packaging:Pallet/as requirements
Description
The Wear-resistant Ceramic Composite Plate For Conveyor Chute is made of alumina or zirconia wear-resistant ceramics, which are vulcanized and inlaid into a steel groove equipped with special rubber under high temperature conditions to form a wear-resistant ceramic composite plate, forming a wear-resistant, impact-resistant, and wear-resistant composite plate. Corrosive wear layer.
Feature
This wear-resistant ceramic composite plate is suitable for working in an environment of -20 degrees to 120 degrees, and is not suitable for high temperature operations, because the rubber will be melted by high temperature.
According to the cushioning property of the rubber layer, this wear-resistant ceramic composite plate is very suitable for the condition of falling bulk materials, protecting the equipment from wear and impact, and saving the cost of maintenance equipment in the factory. Moreover, the weight of the composite plate is lighter than that of the steel plate, and the construction is more convenient.
Technical specification
Series | Rubber |
Bulk density(g/cm3) | 1.4 |
Tensile strenth at break (MPa) | ≥14 |
Elongation at break (%) | ≥250 |
Shore hardness (HA) | 48-65 |
Adhesive between steel and rubber (MPa) | ≥3.5 |
Adhesive between rubber and ceramic (MPa) | ≥3.5 |
Thermal conductivity (normal temperature) (W/M·K) | 2 |
Aging period (years) | ≥1.5 |
Working temperature(℃) | -50-200 |
Series | BM92 | BMG95 |
AL2O3 (%) | 92±0.5 | 95±0.5 |
Bulk density(g/cm3) | ≥3.6 | ≥3.65 |
Compressive strength (MPa) | ≥1050 | ≥1300 |
Bending strength (MPa) | ≥220 | ≥250 |
Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
Rockwell hardness (HRA) | ≥82 | ≥85 |
Loss bulk (cm3) | ≤0.25 | ≤0.2 |
Application
Wear-resistant Ceramic Composite Plate For Conveyor Chute is widely used in coal conveying and ash discharge systems of cement thermal power and material conveying and batching systems in the iron and steel metallurgy industry as anti-wear linings for silos, hoppers, chutes and other equipment.
Alumina ceramic composite pannel is widely used in coal conveying, ash discharge systems, silo hoppers, chutes and other equipment in conveying and batching systems.
Composite Plate Picture
Our ceramic tiles
Our workshop
FAQ
1. Are you are trading company or a factory?
We are a factory, manufacturing high alumina ceramic wear resistant liners in Zibo, China
2. What is your monthly capacity?
500-650ton per month
3. What kinds of ceramic wear resistant liners do you manufacture?
92%alumina liner, 95%alumina liner, T95%alumina liner, zirconia tile liner, ZTA tiles , ceramic-rubber composite plates, wearing compound .
4. What is the delivery time?
If we have stock, the delivery time is within 5-7days after order confirmed. If there is no stock, it is usually 15-20days.
5. Can you manufacture ceramic liner according to customers' desgin?
Yes, we have engineer team and we can produce ceramic parts according to the drawings of the customers.
6. What is the packing?
Bag or carton, and then wooden pallet or wooden box, 20~25tons per 1*20"FCL
7. What is the nearest port?
Qingdao port
