Wear Resistant High Alumina Ceramic Lining and Rubber Ceramic Composited Plate Made by China Qimingxing Factory
We guarantee to give you a timely reply, and look forward to working with all merchants to grow together, through joint efforts, to provide the best quality Wear Resistant Ceramic Snap Fastener, Ceramic wear liners, Anti-Wear Alumina Ceramic Pipe Elbow for you. With our own advanced management and good service concepts, we are well received by users in the industry! Our goal is to build a customer-centric, pioneering, innovative, united and cooperative, honest and trustworthy company.
Product introduction:
High alumina ceramic Lining is a kind of anti-wear and anti-damage material commonly selected by modern enterprises. It is used in anti-wear equipment to resist the impact of materials.
Characteristic
High alumina ceramic lining has high mechanical strength, excellent corrosion resistance, good insulation performance and high temperature resistance, which can effectively protect the equipment and improve the service life and stability of the equipment.
Application:
High alumina ceramic lining is suitable for material conveying systems in industries such as electricity, metallurgy, coal, petroleum, cement, chemical industry, and machinery.
Chemical Composition and Physical Properties:
| Item/Product | 92 Series | 95 Series |
| AL2O3(%) | ≥92 | ≥95 |
| Rockwell hardness(HRA) | ≥82 | ≥85 |
| Wear volume(cm3) | ≤0.25 | ≤0.2 |
| Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
| Bending strength(Mpa) | ≥220 | ≥250 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 |
| Compressive strength(Mpa) | ≥1050 | ≥1300 |
Specification Available:
| Type | Length(mm) |
Width(mm) |
Height(mm) |
| Flat lining | 50~150 | 25~100 | 6~50 |
| Weldable lining | 50~150 | 30~100 | 10~50 |
| Trapezoidal lining | 50~150 | 20~100 | 8~50 |
We promote the development of the Wear Resistant High Alumina Ceramic Lining and Rubber Ceramic Composited Plate Made by China Qimingxing Factory industry through innovation, continuously improve product quality through user feedback, and reflect corporate value by meeting user needs. Welcome to visit our website and do not hesitate to communicate with us. It is precisely because we have a young, united and hard-working group that our company is capable of growing and developing rapidly each year.
