Alumina Grinding Open Hole Balls
video

Alumina Grinding Open Hole Balls

This kind of hammerhead is aluminum oxide hammerhead. In addition to wear resistance and impact resistance, aluminum oxide has the characteristics of acid and alkali resistance and corrosion resistance. The pH value of some materials is acid and alkali. If the hammer head material is not selected well, it is easy to cause hammer head corrosion.
Send Inquiry
Product Introduction

Product Introduction

TITAN Alumina Open Hole Balls combine an alumina ceramic body with a specially formed opening. Their distinctive structure provides an alternative to conventional solid ceramic balls for applications requiring specific media geometry, material durability, and customized internal passages.



Product Overview

Alumina Grinding Open Hole Balls

Alumina Grinding Open Hole Balls are specially shaped ceramic components featuring one or more openings through the ball body. Unlike conventional solid grinding media, their perforated structure provides an internal passage while retaining the basic spherical form. Made from alumina-based ceramic materials, they can be designed for industrial processes where both material properties and structural configuration need to be considered.

How does the alumina ceramic hammer come from?

The wear-resistant ceramic hammer is made by making a small hole in the alumina ceramic ball and inserting a customized steel bar. The main characteristics of alumina ceramic balls are high strength, high hardness, high wear resistance, large ratio, small volume, high temperature resistance, corrosion resistance, less pollution and other excellent characteristics. Alumina ceramic balls are widely used in the finishing and deep processing of thick and hard materials in different types of ceramics, glazes, glass, chemical plants. Compared with ordinary pebbles or natural goose soft stones, its wear resistance is better. Moreover, the alumina ceramic hammer head is resistant to more than 1000 degrees of high temperature. Its service life is also ten to twenty times higher than that of cast stone, wear-resistant alloy cast steel, steel plastic, steel rubber and other materials, which can bring greater economic benefits into play.

Alumina Grinding Open Hole Balls(2)

Physical and chemical indicators





Project

92 Series

75 Series

95 Series

AL2O3(%)

≥92

≥75

≥95

Bulk density(g/cm3)

≥3.60

≥3.26

≥3.65

Water absorption(%)

≤0.02

≤0.02

≤0.01

Abrasion(‰)

≤0.02

≤0.025

≤0.02

Mohs

9

9

≥9

Color

white

white

white

Scope of   application

glaze and   continuous ball mill

glaze and ultra   white brick grinding

glaze and   continuous ball mill

Forming method

isostatic   pressure rolling

isostatic   pressure rolling

isostatic pressure rolling

FAQ





2020042211385713e6dc944be44b4e98b2dd34b1db5b2f

01.What is the difference between open-hole balls and solid alumina grinding balls?

The main difference is the structure. Solid alumina balls have a continuous ceramic body, while open-hole balls contain an internal passage. This changes their geometry and may affect mechanical strength and suitability for particular processes.

02.What material is used to manufacture these ceramic balls?

They are alumina-based ceramic products. The exact alumina content and related physical properties should be confirmed according to the selected grade and technical specification.

03.Can open-hole ceramic balls be used in a ball mill?

Their suitability depends on the grinding mechanism, loading conditions, ball dimensions, and hole design. Please provide your equipment information so the application can be evaluated before selection.

04.Can TITAN customize the ball diameter and hole size?

Customized dimensions and opening configurations can be discussed according to the product design and manufacturing requirements. A technical drawing or sample is helpful for evaluation.

05.What information is needed for a quotation?

Please provide the required quantity, external diameter, hole diameter, alumina content, dimensional tolerances, and intended application. Operating temperature and chemical conditions are also useful when relevant.

06.How do I choose the right alumina grade?

The selection should consider wear conditions, mechanical loading, chemical exposure, and the required service environment. TITAN can review these factors with you to identify an appropriate material option.

Looking for alumina ceramic balls with a specific opening design? Contact TITAN with your required dimensions, hole diameter, material grade, and application details.

Send us your technical drawing or product requirements to discuss a suitable solution and request a quotation.
