Ceramic Glue
Introduction:
It is difficult to connect the ceramics and metal parts of the equipment by traditional methods such as weldings. But it is a good choice to stick ceramics to metal parts with ceramic glue. By using the ceramic glue, ceramics can be firmly pasted on the surface of the equipment which is seriously worn by material's impact crushing.
Properties:
Abrasion resistant ceramic adhesive has the characteristics of high strength, fast curing, excellent abrasion resistance and corrosion resistance.
Chemical Composition and Physical Properties:
| Item/Index | Wear-resistant ceramic adhesive | ||
| Series | BM1041 | BM1011 | BM1141 |
| Color | White | White (light yellow) | Grey/White |
| Density(g/cm3) | 1.28 | 1.66~1.70 | 1.48~1.52 |
| Weight ratio(A:B) | 4:1 | 1:1 | 4:1 |
| Volume ratio(A:B) | 4:1 | 1:1 | 4:1 |
Operation time (200g mixing, min) | 30 | 30 | 30 |
| Full curing time(h) | 24 | 24 | 24 |
Tensile strength(Mpa) GB/T6329-1996 | 65.0 | 65.0 | 35.0 |
Shear strength(Mpa) GB/T7124-2008 | ≥10 | ≥10 | ≥18 |
| Working temperature (℃) | -60~150 | -60~150 | -60~200 |
| Expiration date(years) | 2 | 2 | 2 |
| Item/Idex | Wearing compound ceramic bead filled epoxy |
| Series | BM8229 |
| Color | Brown |
| Density(g/cm3) | 2.25 |
| Weight ratio(A:B) | 2:1 |
| Volumn ratio(A:B) | 2:1 |
Operation time (200g mixing, min) | 30 |
| Full curing time(h) | 24 |
After curing hardness (ShoreD) GB/T2411-2008 | 89.0 |
Compressive strength (Mpa) GB/T1041-2008 | 110.0 |
Tensile strength(Mpa) GB/T6329-1996 | 28.0 |
Shear strength(Mpa) GB/T7124-2008 | 16.0 |
| Working temperature(℃) | -60~120 |
| Expiration date(years) | 2 |
