Product introduction:
The inner wall of the groove is often in a state of high wear due to the long time storage and transportation of materials, which is prone to damage to the inner wall of the groove, resulting in the scrapping of the groove funnel.
Ceramic rubber composite panels by rubber vulcanization technology, special ceramics embedded within the special rubber, ceramic rubber composite lining board, the formation of strong and buffers to wear rubber layer can effectively absorb the impact load, and can effectively protect the ceramic surface, in addition to the steel plate with heavy head bolt and sulfide in together, convenient and quick installation and replacement.
Advantage:
super wear-resistance
impact resistance
corrosion resistance
Chemical Composition and Physical Properties:
| Item/Index | rubber chute liners |
| Bulk density(g/cm3) | 1.4 |
| Tensile strength at break (Mpa) | ≥14 |
| Elongation at break(%) | ≥250 |
| Shore hardness(HA) | 48~65 |
| Adhesive between steel and rubber (Mpa) | ≥3.5 |
| Adhesive between rubber and ceramic (Mpa) | ≥3.5 |
| Thermal conductivity(normal temperature)(W/M*K) | 2 |
| Aging period(years) | ≥1.5 |
| Series | BM92 | BMG95 |
| AL2O3(%) | 92±0.5 | 95±0.5 |
| Bending strength(Mpa) | ≥220 | ≥250 |
| Compressive strength(Mpa) | ≥1050 | ≥1300 |
| Fracture toughness (MPam1/2) | ≥3.70 | ≥3.80 |
| Rockwell hardness(HRA) | ≥82 | ≥85 |
| Wear volume(cm3) | ≤0.5 | ≤0.2 |
| Bulk density(g/cm3) | ≥3.6 | ≥3.65 |
