High Density Alumina Ceramic Grinding Column for Ball Mill
Use equipment: ball mill, mixing mill and polishing machine, etc.
Product performance: high strength, low abrasion, high ratio, high temperature resistance, corrosion resistance, impact resistance.
Sticking to the belief of 'Creating products of high quality and making friends with people from all over the world', we always put the interest of customers in the first place for Zirconium-aluminium Composite Beads, wear resistant ceramic lining, Wear Resistant Ceramic Lining Cube. We have advanced production technology, reasonable price positioning, and perfect after-sales service, which have won the trust of our customers. Respect for science, keep forging ahead, perfect and improve the quality of products is the goal of all staff of the company.
Details
The Ceramic Column for Grinding is a special ceramic grinding medium made of alumina as the main material and sintered at more than 1650 degrees. It has high wear resistance, high hardness, corrosion resistance, high temperature resistance and impact resistance. It is a kind of ideal wear resistant material. Alumina ceramic cylinder is suitable for grinding rubber vulcanization.
Product performance
1.Ceramic Column for Grinding is high strength, low abrasion, high ratio, high temperature resistance, corrosion resistance, impact resistance.
2.The product has good compactness, high hardness, high density, low wear, good regularity and corrosion resistance.
3.The wear-resistant grinding ceramic cylinder has a large contact area, which ensures the purity of the crushed material, improves the grinding efficiency, and can reduce the grinding time.
Packaging method
Double layer film covered woven bag, ton bag, carton ,tray
Physicochemical indexes
95 series | 92 series | |
Al2O3 | 95+ 1 | 92+ 1 |
Fe2O3 | < 0.15 | < 0.2 |
Mohr hardness | 9 | 9 |
Water absorption rate | < 0.01 | < 0.01 |
Bulk density (g/cm3) | > 3.7 | > 3.65 |
Wear allowance | < 0.01 | < 0.01 |
Diameter (mm) | Phi 3-50 | Phi 3-50 |
Specification of alumina grinding column
Diameter, D | 20 | 25 | 30 | 35 | 40 | 50 | |
Plane 45.Chamfer | 10-25 | 20-30 | 30-35 | 35-40 | 40-45 | 50-55 | 50-55 |
Arc round chamfer | 10-25 | 20-30 | 30-35 | 35-40 | 40-45 | 50-55 | 50-55 |
Toughened dry wear-resistant alumina Cylinder
1. Application area: Cement, silica powder, alumina powder, zircon powder, plate corundum, refractory and other powder materials.
2. Use equipment: ball mill, mixing mill and polishing machine, etc.
The production process
Our factory
As one of the best suppliers of High Density Alumina Ceramic Grinding Column for Ball Mill, we have a significant market share and we are proud to be ahead of the pack in the industry. Our company has always taken 'green technology, leading the future' as its corporate purpose, and abides by the corporate spirit of 'integrity, pragmatism, teamwork, and innovation'. We feel that our warm and professional support will bring you pleasant surprises as perfectly as fortune.
