99% High Purity Alumina Ceramic Balls Alumina Ceramic Ball Al2O3
With many years of service experience and sharp market insights, we have achieved a leading level of grinding alumina ceramic, Inert ceramic balls, Wear Resistant High Aluminum Lining Brick research and application service. We always grasp the pulse of the development trend of the international industry, deeply understand the future trend of the market and understand the real needs of consumers. We will continue to achieve leapfrog development with a rigorous attitude and innovative spirit. After years of development and under the support of our customers, our products have been greatly improved from quality to quantity.
Product Introduction
Inert ceramic ball has the characteristics of high strength, high temperature resistance, high pressure resistance, strong acid-base corrosion resistance and good thermal shock performance.High Purity Alumina Filler Ball is mainly used in the high temperature, high pressure and strong corrosive working environment of petrochemical industry, and High Purity Alumina Filler Ball is the most ideal packing in the transformation furnace, reaction furnace and packing tower of the vast petroleum and chemical industry.
The size of the catalyst should be selected according to the size of the catalyst, generally following the 2x rule (or grading), that is, the diameter of the ceramic ball should be twice the diameter of the adjacent catalyst, so that the material distribution is uniform, the pressure drop is small, and the reactor is more optimized.
In a fixed bed reactor, inert ceramic balls or fillers are usually added to the catalyst.
Application method
Generally, two layers shall be laid, one layer close to catalyst shall be laid with 1-3mm ceramic ball, the other layer close to catalyst shall be laid with 4-6mm ceramic ball, and wire mesh shall be laid outside. The screen is mainly used for gas distribution, filtration of small particles of catalyst entrained by gas or filtration of impurities entering the bed. It also prevents the bed from falling and supports the bed. Generally, each specification of ceramic ball is paved with a thickness of 100mm.Didn't notice the standard. In other words, very fine catalyst particles can not be filtered by this method, and other methods are needed to filter these possibly brought out catalysts.
Chemical Composition and Physical Properties
| Series | BMTL80 | BMTL92 | BMTL95 | BMTL99 |
| AL2O3(%) | ≥80 | ≥92 | ≥95 | ≥99 |
| Bulk density(g/cm3) | 2.5~2.8 | ≥2.8 | ≥3.1 | 3.3~3.7 |
| Water ansorption(%) | ≤5 | ≤5 | ≤5 | ≤5 |
| Color | white | white | white | white |
Specification Available
| Specification | Compressive Strength(N) | ||||
| Inch | mm | BMTL80 | BMTL92 | BMTL95 | BMTL99 |
| 1/8" | 3 | 250 | 300 | 500 | 600 |
| 1/4" | 6 | 1200 | 1500 | 2000 | 2500 |
| 3/10" | 8 | 1400 | 1800 | 3000 | 3500 |
| 3/8" | 10 | 2500 | 3000 | 3300 | 4000 |
| 1/2" | 13 | 4000 | 4500 | 5000 | 6000 |
| 3/4" | 19 | 6000 | 7000 | 12000 | 13000 |
| 1" | 25 | 7000 | 9000 | 15000 | 17000 |
| 2" | 50 | 22000 | 25000 | 30000 | 35000 |
Performance table of high purity alumina packing
Product performance | 90 series | 92 series | 95 series | 99 Series |
AI2O3(%) | > 90 | > 92 | > 95 | > 99 |
Fe2O3(%) | < 0.3 | <0.25 | < 0.15 | L< 0.10 |
Compressive strength (60mm) | ≥ 9 (KN / piece) | ≥ 11 (KN / piece) | ≥ 13 (KN / piece) | ≥ 15 (KN / piece) |
Water absorption (%) Moisture content | < 7 | < 6 | < 5 | < 5 |
Bulk density (g/cm3) Bulk density | >2.8 | > 3 | > 3.1 | > 3.3 |
Bulk density (g/cm3) Stacking density | > 1.7 | > 1.9 | > 2 | > 2.15 |
Product pictures
What else we have?
Our production process
Since our establishment, we have focused on R&D, production and sales of 99% High Purity Alumina Ceramic Balls Alumina Ceramic Ball Al2O3, so we have a professional brand image in this field now. Quality shows value, service creates credibility. Our company will always adhere to the business philosophy of product and service, and provide you with excellent products. Our products are widely recognized and trusted by users and can meet continuously changing of economic and social needs.
